24A-D Series Parallel Shaft DC Gearmotor

Model 0189

Bodine Electric, 0189, 83 Rpm, 29.0000 lb-in, 1/17 hp, 130 dc, 24A-D Series Parallel Shaft DC Gearmotor


Speed (rpm) 83
Rated Torque (lb-in) 29
Rated Voltage 130V
Amps (24V Model) 2.6
Amps (130V Model) 0.48
Peak Torque (lb-in) 33
Motor HP 1/17
Gear Ratio 30
Radial Load (lbs) 65
Length XH (inch) 6.72
Weight (lbs) 4.5
Product Type 24A4BEPM-D3
Accessory Shaft NO
HPDecimal 0.0588
Connection Diagram 074 10101

  • 24A Motor provides high starting torque, adjustable speed, and predictable performance under a range of operating conditions.
  • Unvented gearhousing for universal horizontal mounting.
  • Industrial lip type seals on motor and output shafts.
  • Needle bearing on output shaft for increased radial load capacity and long life.
  • Permanently lubricated gearing utilizing oil for long life.
  • Reinforced thermoplastic helical gear on input stage for quietness and hardened steel spur gears on subsequent stages for high output torque and long life.
  • Helical pinion accurately cut on motor shaft for maximum strength and minimum noise.
