Gearmotors for Hazardous Locations

34B-FX Class I, Div 1
Type 34B6BXBL-FX BLDC or Type 34R6BXPP-FX Inverter-Duty Gearmotors. IP-66.

Electrical equipment used in places such as gas pipelines, aircraft hangars, refineries, or industrial coating and mixing facilities must contain special wiring and components. The National Electrical Code (NEC) breaks down areas such as these that may contain explosive concentrations of dust or vapors into classes and divisions. Bodine offers gearmotors and motors that meet both Class I, Division 2, (Groups A ,B, C and D) or the more stringent Class I, Division 1 (Groups C and D) standards.

Our Class I, Division 2 gearmotors meet NEC standards for use in environments where flammable gases or vapors may accidentally be spilled or leak into the operating area. Our Class I, Division 1 gearmotors are engineered to be used in environments where ignitable concentrations of flammable gases, vapors or liquids are likely to exist under normal operating conditions.

These gearmotors and motors are designed for demanding industrial and commercial applications such as scientific and laboratory equipment, chemical processing equipment, pumps, packaging equipment, conveyors and other factory automation equipment in hazardous locations. Our low-voltage models are ideal for mobile agricultural applications, battery or solar powered portable medical devices, chemical injection pumps in remote gas or oil fields, and any other HazLoc applications that run on 12V or 24VDC.

Bodine Hypoid Gearmotors
Hazardous Location Application - Food Processing (except for powders and flour)
Food Processing (except powders & flour)
Hazardous Location Application - Paint Spray Booth / Industrial Painting
Paint Spray Booth / Industrial Painting
Hazardous Location Application - Oil & Gas / Chemical Injection Pumps
Oil & Gas / Chemical Injection Pumps
Hazardous Location Application - Process and Chemical Industry
Process, Chemical, & Cannabis Industries

Power management is critical in many low-voltage applications. Bodine’s new Class I/Div 1, low-voltage brushless DC (EC) gearmotors were designed with battery and solar power use in mind. Whether it is agricultural equipment, a warehouse automation robot (AGV or AMR), a portable medical device, or a chemical injection pump in a remote gas or oil field, we’ll make sure you get the performance you need. Our new high-torque type 34B6BXBL-FX gearmotors are an ideal solution for low-voltage, off-grid and mobile applications in hazardous locations or industrial environments. These new CI/D1 gearmotors and motors meet the IP-66 environmental protection standard. The geared motors are UL certified for CI/D1 and carry the cULus mark.

Benefits of Inverter-Duty Gearmotors. Inverter-duty gearmotors (and motors) feature variable speed, AC three-phase motor windings that are designed with a special winding insulation system to protect them from potential voltage spikes or corona damage caused by the AC “inverter” PWM speed control (=variable frequency drive / VFD). We offer inverter-duty type 34R-FX gearmotors that are certified for CI/D1 or CI/D2 hazardous location applications. In general, AC three-phase gearmotors and motors are more efficient than their AC single-phase (PSC) counterparts, they are more compact, and provide higher output torques in the same size package. In addition, these variable-speed AC gearmotors and motors don’t require brush replacement or brush maintenance. Typical Applications are conveyor systems, food processing equipment, factory automation, pumps, lifts and packaging equipment. Our CI/D2 34R4-FX gearmotors feature a large terminal box with terminal block and meet IP-44. The CI/D1 standard inverter-duty 34R6BXPP-FX models meet IP-66.
