34R-3F Series AC Right Angle Gearmotor

Model 0491

Bodine Electric, 0491, 43 Rpm, 37.0000 lb-in, 1/15 hp, 115 ac, 34R-3F Series AC Right Angle Gearmotor

SPECIFICATIONS

Speed (rpm) 43
Rated Torque (lb-in) 37
Motor HP 1/15
Volts 115
Hz 60
Phases 1
Amps 1
Gear Ratio 40
Radial Load (lbs) 40
Length XH (inch) 8.69
Weight (lbs) 9.3
Connection Diagram 07410296
Capacitor Part Number 49401054
Product Type 34R4BFCI-3F
HPDecimal 0.0667

STANDARD FEATURES
  •     Totally enclosed IP-20 rating
  •     Fan cooled for high output power
  •     Class "B" insulation system operated within Class "A" limits to prolong winding and lubricant life
  •     Aluminum center ring and endshields for high thermal efficiency and light weight
  •     Industrial lip type seals on motor and output shafts
  •     Bronze sleeve bearings on output shaft oiled by felt wicks and reservoir for quietness
  •     Permanently lubricated gearing utilizing semi fluid grease for long life
  •     Bronze worm gear for high shock load capability
  •     Hardened and ground worm gear for strength and long life
