K-2 Series AC Torque Motor
Model 0621
SPECIFICATIONS
| Synchronous Speed (rpm) | 1500/1800 |
| Locked Rotor Torque (oz-in) | 6/7 |
| Power (watts) | 19/22 |
| Voltage (AC) | 115 |
| Frequency (Hz) | 50/60 |
| Phases | 1 |
| Locked Rotor Current (Amps) | .18/.20 |
| Duty Cycle | S3 40% [5 min] |
| Weight (lbs) | 2.25 |
| Connection Diagram | 07410021 |
| Capacitor Part Number | 49401047 |
| Product Type | KCI-26 |
CAD Drawings
Wiring Diagram
Safety Data Sheets
STANDARD FEATURES
- Will operate satisfactorily on 50 or 60 Hz.
- Special rotor provides excellent performance for holding, winding, and tensioning applications.
- Special windings can provide locked rotor or reverse torque intermittently at rated voltage or continuously at reduced voltage.
- Totally enclosed, non-ventilated IP-20 rating.
- Permanently lubricated, noise tested ball bearings.
- Capacitor is included with motor.
Ready to Purchase? Find a Distributor
All prices are in U.S. dollars. Specifications and prices are subject to change without notice. Web price excludes taxes, shipping, and handling charges. Terms & Conditions of Sale
Availability
Order Quantity: 1-25
Chat with us for Current Stock Availability
![Capacitor; plastic box type; 2.3 MFD / 250V [Item 49401047]](https://www.bodine-electric.com/core/files/bodineelectric/cart/28f69e3a880e416062533064147bc24d.jpg)
