22B4-60P Series 130V Inline Planetary BLDC Gearmotors

Model 7029

Bodine Electric, 7029, 28 Rpm, 218.0000 lb-in, 1/8 hp, 130 dc, 22B4-60P Series 130V Inline Planetary BLDC Gearmotors

SPECIFICATIONS

Speed (rpm) 28
Rated Torque (lb-in) 218
Rated Voltage 130V
Amps (130V Model) 0.88
Peak Torque (lb-in) 278
Motor HP 1/8
Gear Ratio 89:1
Radial Load (lbs) 120
Length XH (inch) 8.1
Weight (lbs) 6.2
Product Type 22B4FEBL-60P3
Accessory Shaft NO
HPDecimal 0.125

STANDARD FEATURES
  •  Requires a 130V brushless DC control set for 120° Commutation angle
  • Up to twice the torque of conventional helical / spur parallel shaft gearboxes of similar size
  • Unvented gearhousing mounts in any orientation
  • Permanently lubricated with high-performance lubricant
  • Hardened steel gears for long life and maximum performance
  • Standard backlash < 60 arc minutes
